Product details

DaBai DW

Sensors and machine vision

Orbbec Inc.

DaBai DW

About this product

DaBai DW is an Orbbec active-stereo structured-light depth camera for service-robot navigation and obstacle avoidance. It provides onboard depth processing and USB connectivity for embedded perception. The manufacturer publishes exact-model operating-range and field-of-view specifications; these are retained separately from related DaBai variants.

Model
DaBai DW
Category
Sensors and machine vision, Components

Specifications & evidence

Source-backed claims. Configuration, workload and evidence type matter when comparing products.

Depth fov

Without D2C H79° V62° D91°±3°; with D2C H79° V55° D88.5°±3°

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
深度FOV 不使用 D2C 时 H79° V62° D91°±3° 使用相机 D2C 时 H79° V55° D88.5°±3°

Depth precision

1.0% at 1 m; 1.1% at 2 m; central 81% ROI

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
相对精度 1.0%( 中心 81%区域) @1000mm 1.1%( 中心 81%区域) @2000mm

Depth range

0.2–2.5 m

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
工作距离 0.2m - 2.5m

Dimensions

89.82×25.10×25.10 mm

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
整机尺寸 89.82 ×25.10 ×25.10 mm

Operating temperature

10–40 °C

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
工作温度 10 ℃ ~ 40℃

Power consumption

Average <1.2 W; peak <4 W for ≤3 ms per 33 ms interval

Manufacturer specification

Configuration: Manufacturer Chinese product table; translated English value, original quotation retained.

机器人避障_机器人导航_结构光模组-奥比中光官网
功耗 平均功耗<1.2W 最大功耗< 4.0W(工作状态下每 33ms 持续时间≤3ms)
