Product details

Astra 2

Sensors and machine vision

Orbbec Inc.

Astra 2

About this product

Astra 2 is a structured-light RGB-D camera for accurate indoor depth capture. It combines an Orbbec depth-processing ASIC, an IMU, hardware synchronization and USB 3.0 connectivity. Orbbec supports the exact model through its ROS 2 wrapper for integration into robotics perception systems.

Model
Astra 2
Category
Sensors and machine vision, Components
Product stage
Commercial

Specifications & evidence

Source-backed claims. Configuration, workload and evidence type matter when comparing products.

Data connection

USB 3.0 Type-C

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Data Connection USB 3.0 Type-C

Data output

Point Cloud, Depth Map, IR & RGB

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Data Output Point Cloud, Depth Map, IR & RGB

Depth fov

H58.2° V45.2°

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Depth FOV H58.2° V45.2°

Depth range

*0.6-8m

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Depth Range *0.6-8m

Depth resolution fps

Up to 1600X1200@30fps

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Depth Resolution/FPS Up to 1600X1200@30fps

Depth technology

Structured Light

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Depth Technology Structured Light

Dimensions w h d

144.5 x 45.3 x 38.6 mm

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Dimensions (W*H*D) 144.5 x 45.3 x 38.6 mm

Imu

Supported

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
IMU Supported

Operating environment

0℃ - 35℃; Indoor; 10%-95%RH (non-condensing)

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Operating Environment 0℃ - 35℃; Indoor; 10%-95%RH (non-condensing)

Power consumption

Average < 3W

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Power Consumption Average < 3W

Power input

USB 3.0 Type-C

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Power Input USB 3.0 Type-C

Release date

2023-01-05

Manufacturer specification

Configuration: Manufacturer launch announcement

CES 2023: Orbbec Unveils Two New 3D Cameras
Orbbec Unveils Two New 3D Cameras at CES 2023 January 5, 2023 Share Orbbec , a leading global 3D camera provider, today announced it will be introducing two of its most advanced 3D sensor cameras ever at CES 2023. The Gemini 2, with the widest field of view among Orbbec’s product lines and exceptional sensing range, as well as the second generation structured light camera, the Astra 2. Both cameras have been developed with the Orbbec’s new generation ASIC chip MX6600, which enables high quality depth processing and supports depth/color image registration in different resolutions. With an easy-touse software development kit, on board IMU and multicamera sync support, the two cameras introduce exciting new possibilities in 3D for a variety of industries.

Rgb fov

H74.7° V46.2°

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
RGB FOV H74.7° V46.2°

Rgb resolution fps

Up to 1920X1080@30fps

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
RGB Resolution/FPS Up to 1920X1080@30fps

Sdk support

Orbbec SDK

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
SDK Support Orbbec SDK

Wavelength

850 nm

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Wavelength 850nm

Weight

241 g

Manufacturer specification

Astra Structured Light Camera | Affordable & High Precision
Weight 241g
