FM811-TIX

Sensors and machine vision

Percipio

FM811-TIX

About this product

Discontinued USB 2.0 active-stereo camera with three infrared lasers, RGB-D output and a rolling shutter. Hardware triggering and an IP54 aluminum housing support industrial depth acquisition in legacy systems.

Model
FM811-TIX
Category
Sensors and machine vision, Components
Product stage
Discontinued

Specifications & evidence

Source-backed claims. Configuration, workload and evidence type matter when comparing products.

Data connector

USB 2.0

Manufacturer specification

FM811-TIX manufacturer specifications
Power & Data connector USB 2.0

Depth frame rate and resolution

5 fps @ 1280 x 960 5 fps @ 640 x 480 5 fps @ 320 x 240

Manufacturer specification

Configuration: Manufacturer listed resolution/depth-quality combinations; operating-mode conditions in datasheet

FM811-TIX manufacturer specifications
Frame rate2 @ resolution (Depth) 5 fps @ 1280 x 960 5 fps @ 640 x 480 5 fps @ 320 x 240

Dimensions

130.0 mm x 50.9 mm x 68.8 mm

Manufacturer specification

Configuration: Dimension (excluding interfaces)

FM811-TIX manufacturer specifications
Dimension (excluding interfaces) 130.0 mm x 50.9 mm x 68.8 mm

Hardware trigger

1 trigger input/output, falling-edge trigger

Manufacturer specification

FM811-TIX manufacturer specifications
Hardware trigger 1 trigger input/output, falling-edge trigger

Housing material

Aluminum alloy

Manufacturer specification

FM811-TIX manufacturer specifications
Housing material Aluminum alloy

Illumination

3 x infrared laser (λ = 830 nm)

Manufacturer specification

FM811-TIX manufacturer specifications
Illumination 3 x infrared laser (λ = 830 nm)

Ingress protection

IP54

Manufacturer specification

FM811-TIX manufacturer specifications
Ingress protection IP54

Output data

Depth, RGB, IR, point cloud images

Manufacturer specification

FM811-TIX manufacturer specifications
Output data Depth, RGB, IR, point cloud images

Power consumption

Idle mode: 1.9 W Trigger mode: 3.0 W Continuous mode: 3.5 W

Manufacturer specification

FM811-TIX manufacturer specifications
Power consumption Idle mode: 1.9 W Trigger mode: 3.0 W Continuous mode: 3.5 W

Rgb d alignment

√

Manufacturer specification

FM811-TIX manufacturer specifications
RGB-D Alignment √

Sdk

Percipio Camport SDK; Supported programming language: C, C++, C#, Python

Manufacturer specification

FM811-TIX manufacturer specifications
SDK Percipio Camport SDK; Supported programming language: C, C++, C#, Python

Shutter

Rolling

Manufacturer specification

FM811-TIX manufacturer specifications
Shutter Rolling

Supported platforms

Linux/Windows/ROS

Manufacturer specification

FM811-TIX manufacturer specifications
OS Linux/Windows/ROS

Technology

Active stereo

Manufacturer specification

FM811-TIX manufacturer specifications
Technical principle Active stereo

Temperature

Operating: 0 ℃ ~ 45 ℃ Storage:-10 ℃ ~ 55 ℃

Manufacturer specification

FM811-TIX manufacturer specifications
Temperature Operating: 0 ℃ ~ 45 ℃ Storage:-10 ℃ ~ 55 ℃

Thermal dissipation

Passive

Manufacturer specification

FM811-TIX manufacturer specifications
Thermal dissipation Passive

Trigger connector

M8 A-Code, 5-pin, male connector

Manufacturer specification

FM811-TIX manufacturer specifications
Trigger connector M8 A-Code, 5-pin, male connector

Weight

523 g

Manufacturer specification

Configuration: Weight

FM811-TIX manufacturer specifications
Weight 523 g

Working distance

800 mm ~ 3400 mm

Manufacturer specification

Configuration: Recommended working distance

FM811-TIX manufacturer specifications
Recommended working distance 800 mm ~ 3400 mm
